膜管特性
膜管组态 工业用大流量型并含中央隔板装置
液流量范围 (一支膜管) 10 – 48 m3
/hr (44 – 210 gpm)
中空丝膜种类 X-IND 丝膜
丝膜/胶黏材料 聚丙烯 / 环氧树脂
内容积 (约略)
液相 26.1 L (6.9 gal)
气相 10.6 L (2.8 gal)
Pressure Guidelines*
Maximum Shellside LIQUID Working
Temperature/Pressure
5-50° C, 4.1 bar (41-122° F, 60 psig)
If no vacuum is used, 1.05 bar (15 psig) can be added.
Maximum Applied Gas Pressure
In European Union Countries
4.5 bar (65 psi)
In Rest of World
5.2 bar (75 psi)
Max applied gas pressure is for integrity testing at ambient temperatures. Normal operating pressures are typically
lower.
*Pressures are based on non-dangerous liquids and gasses per the European Union Pressure Equipment Directive
/97/23/EC. See Operating Guide for pressure limits in the European Union with dangerous liquids and gasses. Also,
see Operating Guide for complete temp/pressure limits for housings and membrane.
Note: Liquid pressure should always exceed gas pressure.
Housing Options and Characteristics
材质
Fiber Reinforced Plastic (FRP) for Industrial Use
Exterior finish is gray
法兰接头
液相进出口端
• 3 英寸150级的光滑面法兰( ANSI B16.5)
• 10K的平面法兰80A (JIS B2238)
气相二端
• 1 英寸150级的光滑面法兰( ANSI B16.5)
• 10K的平面法兰50A (JIS B2238)
安装件
1套安装件含2 个支架和2片铁皮条（箍）是分开卖的。它用于支持膜元件水平式或立式安装。
密封圈选项
材质 应用领域
EPDM (ANSI / NSF 61) 一般
重量
膜件干重 33 kg. (73 lbs.)
液相注满水时 57 kg. (125 lbs.)
膜管(内胆)干重 10 kg. (23 lbs.)
装运重量 44 kg. (98 lbs.)
Regulatory
Meets RoHS threshold limits. Complies with the PED 97/23/EC and is manufactured with sound engineering practice.
This contactor is NOT manufactured with FDA compliant materials.
10x28 INDUSTRIAL数据单表
注意: 所有尺寸为一参考代表值
INDUSTRIAL
FRP
279 mm
(11.0 in)
1186 mm
(46.7 in)
247.6 mm
(9.75 in)
Lumenside
Lumenside
Shellside
Shellside
